AISI/SAE 1045 C45 Carbon Steel Bar

AISI/SAE 1045 C45 Carbon Steel Bar

1045 is characterized by medium carbon, medium tensile strength steel, which has quite good strength, machinability and reasonable weldability under hot-rolled conditions. 1045 round steel can be provided with hot rolling, cold drawing, rough turning or turning and polishing. By cold-drawing the 1045 steel bar, the mechanical properties can be improved, the dimensional tolerance can be improved, and the surface quality can be improved.
Certification
Product Description
Factory Workshop
Packing And Delivery

AISI/SAE 1045 C45 Carbon Steel Bar Description

1045 is characterized by medium carbon, medium tensile strength steel, which has quite good strength, machinability and reasonable weldability under hot-rolled conditions. 1045 round steel can be provided with hot rolling, cold drawing, rough turning or turning and polishing. By cold-drawing the 1045 steel bar, the mechanical properties can be improved, the dimensional tolerance can be improved, and the surface quality can be improved.


Scope of Application

1045 steel is widely used in machining, automobile manufacturing, aerospace and other fields.


Product Parameters

Product Name

AISI/SAE 1045 C45 Carbon Steel Bar

Standard

EN/DIN/JIS/ASTM/BS/ASME/AISI, etc.

Common Round Bar Specifications

3.0-50.8 mm, Over 50.8-300mm

Flat Steel Common Specifications

6.35x12.7mm, 6.35x25.4mm, 12.7x25.4mm

Hexagon Bar Common Specifications

AF5.8mm-17mm

Square Bar Common Specifications

AF2mm-14mm, AF6.35mm, 9.5mm, 12.7mm, 15.98mm, 19.0mm, 25.4mm

Length

1-6meters, Size Accept Custom

Diameter(mm)

Hot Rolling Round Bar

25-600

Cold Rolling Square Bar

6-50.8

Hot Rolling Square Bar

21-54

Cold Rolling Hexagon Bar

9.5-65

Cold Rolling Round bar

6-101.6

Forged Rebar

200-1000

Surface Process

Bright, Polished, Black

Other Services

Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.


Chemical Composition

Grade

Mn

S

C

P

Si

Cr

Ni

AISI 1045

0.5-0.8

0.035

0.5-0.42

0.035

0.17-0.37

0.25

0.3


Mechanical Properties

Grade

Tensile Strength (Ksi)min

Elongation(%in50mm)min

Yield Strength 0.2%Proof(ksi)min

Hardness

AISI 1045

600

40

355

229
